MTSW-103-22-L-S-010-LL

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Male Pin Rectangular Connector
PDF
/
Inventory: 6043
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyester, Glass Filled

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series Flex Stack, MTSW
Part Status Active
Termination Kinked Pin, Solder
Connector Type Header, Cuttable
Number of Positions 3
Number of Rows 1
Gender Male
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Male Pin
Current Rating (Amps) 3A
Insulation Height 0.100 2.54mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Contact Length - Post 0.520 13.21mm
Shrouding Unshrouded
Lead Pitch 2.54mm
Contact Finish - Post Tin
Contact Length - Mating 0.010 0.25mm
Overall Contact Length 0.630 16.00mm

Dimensions

Contact Finish Thickness - Mating 10.0μin 0.25μm

Compliance

Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
