MTSW-103-08-F-D-265
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Flex Stack MTSW ROHS3Compliant GENERAL PURPOSE NO Connector Header, Cuttable -55C~125C 3A 3.00muin 0.076mum
PDF
/
Inventory: 7953
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 3.00μin 0.076μm
Technical
Overall Contact Length 0.530 13.46mm
Mating Information NO
Contact Length - Mating 0.265 6.73mm
Contact Finish - Post Tin
Lead Pitch 2.54mm
Shrouding Unshrouded
Contact Length - Post 0.165 4.19mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.100 2.54mm
Current Rating (Amps) 3A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Number of Rows 2
Number of Positions 6
Connector Type Header, Cuttable
ECCN Code EAR99
Termination Solder
Part Status Active
Series Flex Stack, MTSW
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
