LTMM-105-01-G-D-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Shrouded Header HDR 10 POS 2mm Solder ST Thru-Hole Tube
PDF
/
Inventory: 7830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series Flex Stack, LTMM
Feature Board Lock, Keying Slot
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Header
Number of Positions 10
Number of Rows 2
Gender Male
Additional Feature HIGH TEMPERATURE
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Male Pin
Insulation Height 0.190 4.83mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 0.489 inch
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.090 2.29mm
Shrouding Shrouded - 4 Wall
Number Of PCB Rows 2
Contact Length - Mating 0.100 2.54mm
PCB Contact Pattern RECTANGULAR
Body Depth 0.19 inch
Insulation Resistance 5000000000Ohm
Mating Contact Pitch 0.079 inch
Polarization Key CENTER
Dielectric Withstanding Voltage 600VAC V
Dimensions
Contact Finish Thickness - Mating 20.0μin 0.51μm
Contact Finish Thickness - Post 3.00μin 0.076μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
