FTSH-135-01-F-DV-EJ-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Ejector Header HDR 70 POS 1.27mm Solder ST SMD Tube
PDF
/
Inventory: 2833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Polymer
Board Mounting Option PEG
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2015
Series FTSH
JESD-609 Code e3
Feature Board Guide
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Header, Cuttable
Number of Positions 70
Number of Rows 2
Gender Male
HTS Code 8536.69.40.40
Fastening Type Latch Lock/Eject Hooks
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.4A per Contact
Total Number of Contacts 70
Orientation Straight
Depth 5.64mm
Insulation Height 0.099 2.51mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reliability COMMERCIAL
Row Spacing - Mating 0.050 (1.27mm)
Shrouding Unshrouded
Number Of PCB Rows 2
Contact Finish - Post Tin
Contact Length - Mating 0.120 3.05mm
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Mating Contact Pitch 0.05 inch
PCB Contact Row Spacing 4.064 mm
Dimensions
Length 60.22mm
Plating Thickness FLASH inch
Contact Finish Thickness - Mating 3.00μin 0.076μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
