FTSH-120-01-L-DV-EJ-K
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
40 Positions Header, Shrouded Connector 0.050" (1.27mm) Surface Mount Gold
PDF
/
Buying Options
Total Price: USD $4.3
Unit Price: USD $4.3032
≥1 USD $4.3032
≥10 USD $3.89136
≥100 USD $3.407008
≥500 USD $3.157
Inventory: 833
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
Length 41.17mm
Technical
PCB Contact Row Spacing 4.064 mm
Max Current Rating 1.75A
Mating Contact Pitch 0.05 inch
Housing Color Black
UL Flammability Code 94V-0
Body Breadth 0.135 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 0.120 3.05mm
Contact Finish - Post Tin
Number Of PCB Rows 2
Shrouding Unshrouded
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.099 2.51mm
Depth 5.64mm
Orientation Straight
Total Number of Contacts 40
Current Rating (Amps) 3.4A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Lock/Eject Hooks
Number of Rows 2
Number of Positions 40
Connector Type Header, Cuttable
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature End Shrouds, Keying Shroud
JESD-609 Code e3
Series FTSH
Published 2014
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
