FTSH-119-02-L-DV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
SAMTEC FTSH-119-02-L-DV Board-To-Board Connector, FTSH Series, 38 Contacts, Header, 1.27 mm, Solder, 2 Rows
PDF
/
Inventory: 9285
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
Technical
PCB Contact Row Spacing 4.064 mm
Mating Contact Pitch 0.05 inch
Body Depth 0.115 inch
UL Flammability Code 94V-0
Body Breadth 0.135 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 0.075 1.90mm
Contact Finish - Post Tin
Number Of PCB Rows 2
Shrouding Unshrouded
Row Spacing - Mating 0.050 (1.27mm)
Body Length or Diameter 0.95 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.099 2.51mm
Total Number of Contacts 38
Current Rating (Amps) 3.4A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature E.L.P.
Gender Male
Number of Rows 2
Number of Positions 38
Connector Type Header, Cuttable
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series FTSH
Published 2012
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Mounting Option 1 LOCKING
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
