FTSH-111-04-F-DV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 22 POS 1.27mm Solder ST SMD Tube
PDF
/
Buying Options
Total Price: USD $3.72
Unit Price: USD $3.722748
≥1 USD $3.722748
≥10 USD $3.512023
≥100 USD $3.313237
≥500 USD $3.125689
≥1000 USD $2.948766
Inventory: 9646
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 3.00μin 0.076μm
Plating Thickness 3μin
Length 13.97mm
Technical
PCB Contact Row Spacing 4.064 mm
Mating Contact Pitch 0.05 inch
UL Flammability Code 94V-0
Body Breadth 0.135 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 0.150 3.81mm
Contact Finish - Post Tin
Number Of PCB Rows 2
Shrouding Unshrouded
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.099 2.51mm
Depth 3.43mm
Orientation Straight
Total Number of Contacts 22
Current Rating (Amps) 3.4A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature E.L.P.
Gender Male
Number of Rows 2
Number of Positions 22
Connector Type Header, Cuttable
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series FTSH
Published 2015
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Mounting Option 1 LOCKING
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
