FTR-134-56-T-S-P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 34 POS 1.27mm Solder ST SMD
PDF
/
Inventory: 6555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Mating Contact Pitch 0.05 inch
Body Breadth 0.096 inch
PCB Contact Pattern STAGGERED
Contact Length - Mating 0.405 10.29mm
Number Of PCB Rows 2
Shrouding Unshrouded
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.100 2.54mm
Total Number of Contacts 34
Current Rating (Amps) 3.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature PICK & PLACE PAD
Gender Male
Number of Rows 1
Number of Positions 34
Connector Type Header
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Feature Pick and Place
JESD-609 Code e3
Series FTR
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
