FTMH-111-02-F-DV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
E.L.P. Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $4.44
Unit Price: USD $4.444
≥1 USD $4.444
≥10 USD $4.0348
≥100 USD $3.5552
≥500 USD $3.02192
≥1000 USD $2.57752
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series FTMH
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Header
Number of Positions 22
Number of Rows 2
Gender Male
Additional Feature E.L.P.
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 2.8A per Contact
Total Number of Contacts 22
Terminal Pitch 1mm
Insulation Height 0.059 1.50mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.039 1.00mm
Insulation Color Black
Row Spacing - Mating 0.039 (1.00mm)
Shrouding Unshrouded
Contact Finish - Post Tin
Contact Length - Mating 0.075 1.90mm
Dimensions
Contact Finish Thickness - Mating 3.00μin 0.076μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
