90814-3808
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 8POS 1.27MM SMD GOLD
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.556357
≥1 USD $1.556357
≥10 USD $1.468261
≥100 USD $1.385151
≥500 USD $1.306741
≥1000 USD $1.232775
Inventory: 1167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Surface Mount
Housing Material Nylon
Technical
Published 2010
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Blade Pin
Number of Positions 8
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Voltage - Rated 250V
Additional Feature PICOFLEX, POLARIZED, STAGGERED CONFIGURATION
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 8
Orientation Vertical
Current Rating 2.4A
Number of Conductors ONE
Reference Standard UL
Voltage - Rated AC 250V
Reliability COMMERCIAL
Number Of PCB Rows 2
Contact Length - Mating 2.159mm
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
UL Flammability Code 94V-0
Contact Resistance 15mOhm
Body/Shell Style RECEPTACLE
Max Voltage Rating (DC) 250.25kV
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
