90814-0014

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings Obsolete
PDF
/
Inventory: 3279
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Brass
Contact Plating Tin
Mount Surface Mount
Housing Material Thermoplastic

Technical

Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Blade Pin
Number of Positions 14
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature PICOFLEX, POLARIZED, STAGGERED CONFIGURATION
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 14
Orientation Vertical
Current Rating 1.2A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 1.27mm
Contact Length - Mating 2.159mm
PCB Contact Pattern STAGGERED
UL Flammability Code 94V-0
Contact Resistance 15mOhm
Body/Shell Style RECEPTACLE
Max Voltage Rating (DC) 250.25kV
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
