90814-0010

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings Obsolete
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.634977
≥1 USD $0.634977
≥10 USD $0.599034
≥100 USD $0.565128
≥500 USD $0.533141
≥1000 USD $0.502963
Inventory: 4515
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Technical

Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Body/Shell Style RECEPTACLE
Contact Resistance 15mOhm
UL Flammability Code 94V-0
PCB Contact Pattern STAGGERED
Contact Length - Mating 2.159mm
Lead Pitch 1.27mm
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 1.2A
Orientation Vertical
Total Number of Contacts 10
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature PICOFLEX, POLARIZED, STAGGERED CONFIGURATION
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 10
Connector Type Blade Pin
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2005

Physical

Housing Material Thermoplastic
Mount Surface Mount
Contact Plating Tin
Contact Material Brass
