90800-0004
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 1.27MM 4P RA HEADER LO-PRO W/KINK TAIL
PDF
/
Inventory: 992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Total Number of Contacts 4
Orientation Vertical
Depth 7.95mm
Current Rating 1.2A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Body Breadth 0.276 inch
Housing Color Black
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Durability 30 Cycles
Contact Pattern RECTANGULAR
Subcategory Headers and Edge Type Connectors
Additional Feature STAGGERED CONFIGURATION
Gender Male
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2006
Dimensions
Length 8.86mm
Plating Thickness 200μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 7 Weeks
