90325-9020
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 20POS 1.27MM TIN T/H
PDF
/
Buying Options
Total Price: USD $1.57
Unit Price: USD $1.572339
≥1 USD $1.572339
≥10 USD $1.483342
≥100 USD $1.399375
≥500 USD $1.320168
≥1000 USD $1.245441
Inventory: 4107
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type BOARD
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Board Mounting Option PEG
Technical
Published 2005
Pbfree Code icon-pbfree yes
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 2
Additional Feature STAGGERED CONFIGURATION
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 20
Terminal Pitch 1.27mm
Reach Compliance Code compliant
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 1.167 inch
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 105°C
Body Breadth 0.235 inch
Contact Gender MALE
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Body Depth 0.252 inch
Rated Current (Signal) 1.2A
Contact Resistance 15mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.05 inch
Body/Shell Style RECEPTACLE
Termination Type SOLDER
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
PCB Contact Row Spacing 2.54 mm
Durability 30 Cycles
Contact Pattern RECTANGULAR
Insulator Color BLACK
Dimensions
Plating Thickness 200u inch
Length - Termination 0.126 inch
Compliance
RoHS Status RoHS Compliant
Alternative Model
