90131-0771
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 2.54MM CGRIDIII HDR 22P VERT DR SEL AU
PDF
/
Inventory: 4467
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Through Hole
Housing Material Polyester
Technical
Published 2008
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Male
Voltage - Rated 350V
Additional Feature C-GRID III
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Current Rating 3A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.1 inch
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 22
Contact Length - Mating 6.7564mm
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Body Depth 0.098 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 350VDC V
Contact Pattern RECTANGULAR
Insertion Force-Max .973 N
Withdrawl Force-Min .1946 N
Dimensions
Plating Thickness 15μin
Length - Termination 0.114 inch
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
