90130-1124
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 24POS .100" STR TIN
PDF
/
Buying Options
Total Price: USD $3.24
Unit Price: USD $3.23528
≥1 USD $3.23528
≥10 USD $3.052151
≥100 USD $2.879396
≥500 USD $2.716408
≥1000 USD $2.562645
Inventory: 7723
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length - Termination 0.114 inch
Plating Thickness 118μin
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 350.35kV
Durability 500 Cycles
Dielectric Withstanding Voltage 700VAC V
Body/Shell Style RECEPTACLE
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.515 inch
UL Flammability Code 94V-0
Body Breadth 0.384 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.7564mm
Number of Contacts 24
Lead Pitch 2.54mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Voltage - Rated AC 350V
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated DC 350V
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature C-GRID, SHROUDED
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2009
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 9 Weeks
