90121-0771
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 11POS .100 R/A GOLD
PDF
/
Inventory: 5483
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Glow Wire Compliant Non-compliant
Insertion Force-Max .973 N
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 350VDC V
Number of Circuits 10
Body/Shell Style RECEPTACLE
Insulation Resistance 5000000000Ohm
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.7564mm
Number of Contacts 11
Lead Pitch 2.54mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature C-GRID III
Voltage - Rated 350V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Bulk
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material Brass
Supply Chain
Factory Lead Time 13 Weeks
