90121-0127
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 2.54MM CGRIDIII HDR 7P R/A SR TIN
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.796592
≥1 USD $0.796592
≥10 USD $0.751502
≥100 USD $0.708965
≥500 USD $0.668831
≥1000 USD $0.630974
Inventory: 4095
Minimum: 1
-
+
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Polyester
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 7
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Additional Feature C-GRID III
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 350V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 7
Orientation Right Angle
Current Rating 3A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Lead Pitch 2.54mm
Contact Length - Mating 6.7564mm
PCB Contact Pattern RECTANGULAR
Contact Gender Male
UL Flammability Code 94V-0
Lead Length 2.9mm
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 350VDC V
Contact Pattern RECTANGULAR
Insertion Force-Max 3.0024 N
Mating Post Length 6.75mm
Glow Wire Compliant Non-compliant
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
