87438-1133
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 11POS 1.5MM R/A SMD
PDF
/
Inventory: 4601
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Contact Plating Lead, Tin
Mount Surface Mount
Insulation Material GLASS FILLED NYLON
Technical
Packaging Cut Tape
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 11
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Beige
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature LOW PROFILE, SHROUDED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.5mm
Total Number of Contacts 11
Orientation Right Angle
Reach Compliance Code unknown
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.7 inch
Number Of PCB Rows 1
Lead Pitch 1.5mm
Contact Length - Mating 2.6924mm
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Body Depth 0.226 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 40mOhm
Body/Shell Style RECEPTACLE
Max Voltage Rating (AC) 350V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Contact Pattern RECTANGULAR
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
