87438-0433
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 4POS 1.5MM R/A SMD
PDF
/
Inventory: 2229
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.226 inch
Operating Temperature (Min) -25°C
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 2.6924mm
Lead Pitch 1.5mm
Number Of PCB Rows 1
Body Length or Diameter 0.287 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Right Angle
Total Number of Contacts 4
Pitch 1.4986mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature LOW PROFILE, SHROUDED
Gender Male
Number of Rows 1
Color Beige
Number of Positions 4
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Published 2005
Packaging Cut Tape
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Lead, Tin
Contact Material Brass
