87333-4420
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 44POS 2MM R/A GOLD
PDF
/
Inventory: 7680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Nylon
Technical
Published 2004
Part Status Discontinued
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 44
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Voltage - Rated 125V
Additional Feature MILLI-GRID, POLARIZED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.0066mm
Total Number of Contacts 44
Orientation Right Angle
Reach Compliance Code unknown
Current Rating 2A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.0066 mm
Number Of PCB Rows 2
Lead Pitch 2mm
Contact Length - Mating 3.5814mm
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
UL Flammability Code 94V-0
Body Depth 0.331 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Body/Shell Style RECEPTACLE
Polarization Key CTR W/GUIDE SLOTS
Dielectric Withstanding Voltage 1000VAC V
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Dimensions
Height 6.3mm
Length 46.6mm
Width 6.4mm
Plating Thickness 15μin
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
