87332-4020
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 40POS 2MM VERT SMD
PDF
/
Inventory: 2868
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 15μin
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.5814mm
Lead Pitch 2mm
Number Of PCB Rows 2
Row Spacing - Mating 2.0066 mm
Body Length or Diameter 1.679 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 40
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature POLARIZED
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 40
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Published 2004
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
