87089-2016
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 20POS 2MM VERT GOLD
PDF
/
Inventory: 7697
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Plating Thickness 15μin
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 2A
Body Depth 0.059 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender Male
Body Breadth 0.157 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.9878mm
Lead Pitch 2mm
Number Of PCB Rows 2
Row Spacing - Mating 2.0066 mm
Body Length or Diameter 0.783 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 2A
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 20
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature MILLI-GRID
Voltage - Rated 125V
Number of Rows 2
Color Black
Number of Positions 20
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Physical
Housing Material Polyamide
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
