70543-0052
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings SL 18 CKT W-T-B SHRO
PDF
/
Buying Options
Total Price: USD $5.74
Unit Price: USD $5.737544
≥1 USD $5.737544
≥10 USD $5.412782
≥100 USD $5.106393
≥500 USD $4.817356
≥1000 USD $4.544676
Inventory: 2510
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 5.08mm
Length 48.3mm
Height 11.4mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Durability 25 Cycles
Dielectric Withstanding Voltage 600VAC V
Polarization Key CTR W/GUIDE SLOTS
ELV Compliant
Body/Shell Style RECEPTACLE
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.465 inch
UL Flammability Code 94V-0
Body Breadth 0.26 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Lead Pitch 2.54mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Vertical
Total Number of Contacts 18
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature LATCHED
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 18
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Physical
Housing Material Plastic
Material Brass
Mount Through Hole
Contact Plating Tin
Contact Material Bronze
