70247-4052
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 40CKT R/A SHDR HDR
PDF
/
Buying Options
Total Price: USD $5.9
Unit Price: USD $5.903908
≥1 USD $5.903908
≥10 USD $5.569722
≥100 USD $5.254454
≥500 USD $4.957037
≥1000 USD $4.676443
Inventory: 1202
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Plating Thickness 30μin
Length 58.42mm
Height 7.6mm
Technical
Glow Wire Compliant Non-compliant
Current Rating (Max) 2A
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250V
Durability 50 Cycles
Dielectric Withstanding Voltage 900VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 125V
ELV Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 12GOhm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Body Breadth 0.35 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Lead Pitch 2.54mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 2.5A
Depth 6.3mm
Orientation Right Angle
Total Number of Contacts 40
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature SHROUDED
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Number of Positions 40
Connector Type Male Pin
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Physical
Housing Material Polyester
Mount Surface Mount, Through Hole
Contact Plating Gold
Contact Material Bronze
