70246-3402
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 34CKT SHRD HDR
PDF
/
Inventory: 6183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 34
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Male
Additional Feature SHROUDED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 34
Orientation Vertical
Current Rating 2.5A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Lead Pitch 2.54mm
Contact Length - Mating 6.096mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.35 inch
UL Flammability Code 94V-0
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Body Depth 0.365 inch
Contact Style SQ PIN-SKT
Insulation Resistance 12GOhm
Body/Shell Style RECEPTACLE
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 900VAC V
Max Voltage Rating (DC) 250V
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material COPPER ALLOY
Dimensions
Plating Thickness 30μin
Length - Termination 0.135 inch
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
