68301-1015
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER SMD 4POS 2.54MM
PDF
/
Inventory: 3309
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Durability 25 Cycles
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Insulation Resistance 50000000000Ohm
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.09 inch
Contact Gender Male
Body Breadth 0.098 inch
PCB Contact Pattern STAGGERED
Contact Length - Mating 6.096mm
Number of Contacts 4
Lead Pitch 2.54mm
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Reach Compliance Code unknown
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN OVER NICKEL
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
JESD-609 Code e3
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold, Tin
Contact Material Bronze
