68301-1010
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 4POS .100 VERT 15AU
PDF
/
Inventory: 8009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Durability 25 Cycles
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Insulation Resistance 50000000000Ohm
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.09 inch
Contact Gender Male
Body Breadth 0.098 inch
PCB Contact Pattern STAGGERED
Contact Length - Mating 6.096mm
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 2A
Orientation Vertical
Total Number of Contacts 4
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Voltage - Rated 250V
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
JESD-609 Code e3
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
