68301-1009
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 3POS .100" VERT 15AU
PDF
/
Inventory: 7124
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Technical
Contact Pattern RECTANGULAR
Durability 25 Cycles
Body/Shell Style RECEPTACLE
Insulation Resistance 50000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.09 inch
UL Flammability Code 94V-0
Body Breadth 0.098 inch
PCB Contact Pattern STAGGERED
Contact Length - Mating 6.096mm
Number of Contacts 3
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
