53779-0790
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 7POS 1.25MM R/A SMD
PDF
/
Inventory: 1692
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Surface Mount
Housing Material Thermoplastic
Technical
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 7
Color Natural
Number of Rows 1
Gender Male
Voltage - Rated 125V
Additional Feature PANELMATE, LOW PROFILE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.2446mm
Total Number of Contacts 7
Orientation Right Angle
Reach Compliance Code unknown
Current Rating 1A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Contact Length - Mating 2.5908mm
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 85°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Rated Current (Signal) 1A
Contact Style BLADE PIN-SKT
Contact Resistance 20mOhm
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 250VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 2.085 N
Glow Wire Compliant Non-compliant
Dimensions
Height 1.85mm
Length 13.9mm
Width 5.5mm
Compliance
RoHS Status Non-RoHS Compliant
