53505-3090
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 30POS 1.25MM STR SMD
PDF
/
Inventory: 7069
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 6mm
Length 24.9mm
Height 4.85mm
Technical
Glow Wire Compliant Non-compliant
Insulator Color BLACK
Withdrawl Force-Min .5004 N
Contact Pattern RECTANGULAR
Polarization Key ENDS
Body/Shell Style RECEPTACLE
Insulation Resistance 100000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.191 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 1.397 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 30
Pitch 1.2446mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature POLARIZED, SHROUDED
Gender Male
Number of Rows 2
Number of Positions 30
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Published 2003
Physical
Housing Material Plastic
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
