53325-1260

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Male Pin Rectangular Connector
PDF
/
Inventory: 2693
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length 27.3mm

Technical

Number of Circuits 11
Contact Resistance 20mOhm
Housing Color White
UL Flammability Code 94V-0
Contact Gender MALE
Number of Contacts 12
Current Rating 2A
Depth 7.95mm
Orientation Right Angle
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
HTS Code 8536.69.40.40
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2004

Physical

Housing Material Polybutylene
Mounting Type BOARD
Contact Plating Tin
Contact Material Brass

Supply Chain

Factory Lead Time 7 Weeks
