53324-1160
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 2MM 11POS PCB TIN
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.756309
≥1 USD $0.756309
≥10 USD $0.713504
≥100 USD $0.673119
≥500 USD $0.635013
≥1000 USD $0.599077
Inventory: 5921
Minimum: 1
-
+
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Nylon
Technical
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 11
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Voltage - Rated 125V
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Total Number of Contacts 11
Orientation Vertical
Current Rating 2A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Contact Length - Mating 3.429mm
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Body Depth 0.236 inch
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
