53313-0615
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
POLARIZED Male Pin Rectangular Connector
PDF
/
Inventory: 3585
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.138 inch
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED RIB(S)
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 0.5A
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Body Breadth 0.335 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.81mm
Number Of PCB Rows 2
Row Spacing - Mating 2.4892 mm
Body Length or Diameter 0.449 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Vertical
Total Number of Contacts 6
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature POLARIZED
Gender Male
Number of Rows 2
Color Grey
Number of Positions 6
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Physical
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mount Through Hole
Contact Plating Lead, Tin
Contact Material NOT SPECIFIED
