53290-1210
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 12POS 2MM VERT TIN
PDF
/
Inventory: 1462
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Technical
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.079 inch
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Body Depth 0.236 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Terminal Pitch 2mm
Orientation Vertical
Total Number of Contacts 12
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature NONE
Gender Male
Number of Rows 1
Number of Positions 12
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Physical
Mounting Style STRAIGHT
Mounting Option 1 DETENT
Housing Material Plastic
Mounting Type BOARD
Contact Plating Tin
Contact Material Brass
