53290-0310

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description CONN HEADER 3POS 2MM VERT TIN
PDF
/
Inventory: 2283
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Technical

Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.302mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 1.5A
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 3
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature NONE
Voltage - Rated 125V
Gender Male
Number of Rows 1
Number of Positions 3
Connector Type Male Pin
ECCN Code EAR99
Termination Press-Fit
Part Status Discontinued
Published 2001

Physical

Housing Material Plastic
Mount Through Hole
Contact Plating Tin
Contact Material Brass
