53261-1490
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Shrouded Header HDR 14 POS 1.25mm Solder RA SMD Embossed T/R
PDF
/
Inventory: 1480
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Lead, Tin
Mount Surface Mount
Housing Material Nylon
Technical
Packaging Cut Tape
Published 2011
Part Status Discontinued
Termination Solder
ECCN Code EAR99
Connector Type Blade Pin
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Beige
Number of Rows 1
Gender Male
Voltage - Rated 125V
Additional Feature POLARIZED, SHROUDED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.25mm
Orientation Right Angle
Reach Compliance Code unknown
Current Rating 1A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 14
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Body Depth 0.205 inch
Rated Current (Signal) 1A
Contact Resistance 20mOhm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 250VAC V
Durability 30 Cycles
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Dimensions
Height 3.4mm
Length 22.6mm
Width 4.2mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
