53261-1290
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 12POS 1.25MM R/A SMD
PDF
/
Inventory: 962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 4.2mm
Length 20.1mm
Height 3.4mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Durability 30 Cycles
Dielectric Withstanding Voltage 250VAC V
Body/Shell Style RECEPTACLE
Contact Resistance 20mOhm
Rated Current (Signal) 1A
Body Depth 0.205 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Right Angle
Total Number of Contacts 12
Pitch 1.2446mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature POLARIZED, SHROUDED
Gender Male
Number of Rows 1
Color Beige
Number of Positions 12
Connector Type Blade Pin
ECCN Code EAR99
Termination Solder
Packaging Cut Tape
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Lead, Tin
Contact Material Bronze
