53254-1310
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Non-RoHS Compliant COMMERCIAL UL CSA POLARIZED HOUSING Connector Male Pin 20mOhm 85C 0.5A 500VAC V
PDF
/
Inventory: 9342
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.65mm
Length 28mm
Height 4.2mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 0.5A
Body Depth 0.287 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -20°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.302mm
Number of Contacts 13
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Right Angle
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature DOVETAILED MATING GUIDES
Gender Male
Number of Rows 1
Color Natural
Connector Type Male Pin
ECCN Code EAR99
Termination Kinked Pin
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Lead, Tin
Contact Material Brass
