53253-0810
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
DOVETAILED MATING GUIDES Rectangular Connector Header
PDF
/
Inventory: 4327
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key HOUSING SIDE
Body/Shell Style RECEPTACLE
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 0.5A
UL Flammability Code 94V-0
Operating Temperature (Min) -20°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.302mm
Number Of PCB Rows 1
Body Length or Diameter 0.709 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Vertical
Total Number of Contacts 8
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature DOVETAILED MATING GUIDES
Gender Male
Number of Rows 1
Color Natural
Number of Positions 8
Connector Type Male Pin
ECCN Code EAR99
Termination Kinked Pin
Physical
Insulation Material NYLON
Mount Through Hole
Contact Plating Lead, Tin
Contact Material NOT SPECIFIED
