53048-1310
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
GLOVE, POLYAMIDE, L/FREE, PU, SIZE 6 - More Details
PDF
/
Inventory: 8610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Housing Material Nylon
Technical
Published 2000
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Blade Pin
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Additional Feature POLARIZED, SHROUDED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 125V
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.25mm
Orientation Right Angle
Current Rating 1A
Number of Conductors ONE
Reliability COMMERCIAL
Number Of PCB Rows 1
Lead Pitch 1.25mm
Number of Contacts 13
PCB Contact Pattern RECTANGULAR
Contact Gender Male
UL Flammability Code 94V-0
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Body/Shell Style RECEPTACLE
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Dimensions
Height 3.5mm
Length 18mm
Width 5.5mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
