53015-1310

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description CONN HEADER R/A 13POS 2MM
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.150025
≥1 USD $1.150025
≥10 USD $1.084928
≥100 USD $1.023525
≥500 USD $0.965583
≥1000 USD $0.910932
Inventory: 5296
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Housing Material Nylon

Technical

Published 2000
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 13
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Color White
Number of Rows 1
Gender Male
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 125V
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Total Number of Contacts 13
Orientation Right Angle
Current Rating 2A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Lead Pitch 2mm
Contact Length - Mating 3.0988mm
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Body Depth 0.234 inch
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1GOhm
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
