5055681271

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.7304
≥100 USD $0.608784
Inventory: 14083
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Brass
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Polyamide (PA), Nylon, Glass Filled

Technical

Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series Micro-Lock PLUS 505568
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Header
Number of Positions 12
Applications Automotive, General Purpose, Industrial
Number of Rows 1
Voltage - Rated 50VAC/DC
HTS Code 8536.69.40.30
Fastening Type Push-Pull
Contact Finish - Mating Tin
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Current Rating (Amps) Varies by WireGAuge
Total Number of Contacts 12
Insulation Height 0.165 4.20mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.049 1.25mm
Insulation Color Black
Reference Standard UL
Shrouding Shrouded - 4 Wall
Empty Shell NO

Dimensions

Contact Finish Thickness - Mating 39.4μin 1.00μm
Contact Finish Thickness - Post 39.4μin 1.00μm
Stack Height (Mating) 7.4mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
