5054482071
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.2704
≥1 USD $2.2704
≥10 USD $2.00112
≥100 USD $1.591832
Inventory: 1564
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 39.4μin 1.00μm
Contact Finish Thickness - Mating 39.4μin 1.00μm
Technical
Shrouding Shrouded - 4 Wall
Insulation Color Black
Pitch - Mating 0.049 1.25mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.352 8.95mm
Current Rating (Amps) Varies by WireGAuge
Contact Type Male Pin
Contact Finish - Mating Tin
Fastening Type Latch Holder
HTS Code 8536.69.40.30
Voltage - Rated 50VAC/DC
Number of Rows 2
Applications General Purpose, Industrial, Lighting
Number of Positions 20
Connector Type Header
ECCN Code EAR99
Termination Solder
Part Status Active
Feature Pick and Place, Solder Retention
Series Micro-Lock PLUS 505448
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Insulation Material Polyamide (PA), Nylon
Contact Shape Square
Mounting Type Surface Mount, Right Angle
Contact Material Brass
Supply Chain
Factory Lead Time 17 Weeks
