5054331881
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.21528
≥100 USD $1.00364
Inventory: 10371
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 8.6mm
Contact Finish Thickness - Post 39.4μin 1.00μm
Contact Finish Thickness - Mating 39.4μin 1.00μm
Technical
Empty Shell NO
Body Breadth 0.331 inch
Shrouding Shrouded - 4 Wall
Reference Standard UL
Insulation Color Black
Pitch - Mating 0.049 1.25mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.285 7.25mm
Total Number of Contacts 18
Current Rating (Amps) Varies by WireGAuge
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
Contact Finish - Mating Tin
Fastening Type Latch Holder
HTS Code 8536.69.40.30
Voltage - Rated 50VAC/DC
Number of Rows 2
Applications Automotive, General Purpose, Industrial
Number of Positions 18
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Pick and Place, Solder Retention
Series Micro-Lock PLUS 505433
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Insulation Material Polyamide (PA), Nylon
Contact Shape Square
Mounting Type Surface Mount
Contact Material Brass
Supply Chain
Factory Lead Time 13 Weeks
