44432-1201
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Connector, Header, 12Pos, 2Row, 3Mm Rohs Compliant: Yes
PDF
/
Buying Options
Total Price: USD $3.14
Unit Price: USD $3.141202
≥1 USD $3.141202
≥10 USD $2.963401
≥100 USD $2.795658
≥500 USD $2.637409
≥1000 USD $2.488126
Inventory: 950
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 11.9mm
Length 25mm
Height 11.6mm
Technical
Glow Wire Compliant Non-compliant
Withdrawl Force-Min 3.614 N
Insertion Force-Max 11.5648 N
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Durability 30 Cycles
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 100mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.457 inch
Lead Length 3.3mm
UL Flammability Code 94V-0
Contact Gender Male
Body Breadth 0.469 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 12
Lead Pitch 3mm
Number Of PCB Rows 2
Row Spacing - Mating 2.9972 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Orientation Vertical
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature POLARIZED
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2008
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 10 Weeks
