44428-1602
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 16POS 3MM R/A GOLD
PDF
/
Buying Options
Total Price: USD $6.06
Unit Price: USD $6.063455
≥1 USD $6.063455
≥10 USD $5.72024
≥100 USD $5.396462
≥500 USD $5.091001
≥1000 USD $4.802819
Inventory: 1400
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.138 inch
Plating Thickness 15μin
Technical
Glow Wire Compliant Non-compliant
Withdrawl Force-Min 3.614 N
Insertion Force-Max 11.5648 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.686 inch
Empty Shell NO
UL Flammability Code 94V-0
Body Breadth 0.469 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Lead Pitch 3mm
Number Of PCB Rows 2
Row Spacing - Mating 2.9972 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Orientation Right Angle
Total Number of Contacts 16
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature WITH TRAY PACKAGING
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 16
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2008
Physical
Housing Material Thermoplastic
Shell Material GLASS FILLED POLYAMIDE
Mount Through Hole
Contact Plating Gold
Contact Material Brass
Supply Chain
Factory Lead Time 10 Weeks
