43650-1215
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER VERT 12POS 3MM
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.328025
≥1 USD $2.328025
≥10 USD $2.196249
≥100 USD $2.071935
≥500 USD $1.954651
≥1000 USD $1.844012
Inventory: 6946
Minimum: 1
-
+
Technical Details
Technical
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3mm
Total Number of Contacts 12
Orientation Vertical, Right Angle
Current Rating 5A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 1
Lead Pitch 3mm
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Body Depth 0.39 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Durability 30 Cycles
Max Voltage Rating (DC) 250.25kV
Contact Pattern RECTANGULAR
Withdrawl Force-Min 3.0024 N
Halogen Free Low Halogen
Glow Wire Compliant Compliant
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Additional Feature MICRO-FIT 3.0, POLARIZED
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 12
Connector Type Male Pin
ECCN Code EAR99
Termination Press-Fit
Pbfree Code yes
JESD-609 Code e3
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Tin
Contact Material Brass
