43650-1012
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 10POS 3MM RT ANG SMD
PDF
/
Buying Options
Total Price: USD $2.7
Unit Price: USD $2.695729
≥1 USD $2.695729
≥10 USD $2.543137
≥100 USD $2.399189
≥500 USD $2.263386
≥1000 USD $2.135269
Inventory: 1518
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Technical
Glow Wire Compliant Compliant
Halogen Free Low Halogen
Withdrawl Force-Min 3.0024 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.39 inch
UL Flammability Code 94V-0
Contact Gender Male
PCB Contact Pattern RECTANGULAR
Lead Pitch 3mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 5A
Orientation Right Angle
Total Number of Contacts 10
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Additional Feature MICRO-FIT 3.0, POLARIZED
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 10
Connector Type Male Pin, Plug, Socket
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2007
Physical
Housing Material Liquid Crystal Polymer
Mount Surface Mount
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 9 Weeks
