39-29-9043
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER VERT 4POS 4.2MM
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.668855
≥1 USD $0.668855
≥10 USD $0.630996
≥100 USD $0.595276
≥500 USD $0.56158
≥1000 USD $0.529794
Inventory: 1199
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height 12.8mm
Technical
Glow Wire Compliant Non-compliant
Current Rating (Max) 9A
Halogen Free Low Halogen
Withdrawl Force-Min 3.1136 N
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 600.6kV
Durability 30 Cycles
PCB Contact Row Spacing 5.5118 mm
Dielectric Withstanding Voltage 1500VAC V
Polarization Key HOUSING SIDE
Body/Shell Style PLUG
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Empty Shell NO
Contact Gender Male
Body Breadth 0.38 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 4
Number Of PCB Rows 2
Row Spacing - Mating 4.191 mm
Body Length or Diameter 0.653 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 8A
Orientation Vertical
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature MINI-FIT JR.
Voltage - Rated 600V
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Published 2006
Physical
Housing Material Nylon
Shell Material POLYAMIDE66
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
